WFII-B双流齿轮传动喂丝机

主要技术参数Main Technical Data

喂线速度Feeding Speed            0-420m/min

电机Motor                               1×11KW

防护等级 Elec.Protection            IP55/IP54

电源Power Supply                     AC380/400/415V,50/60Hz

气源Media                               空气压力Air Pressure:0.5-0.8Mpa

重量Weight                              1500Kg

送线轮直径Dia.Wheel                140mm

尺寸Dimension                          长(L)1370mm  宽（W）880  高（H）2170mm
